Big Tex 10SR 9,990#,TA,SR DUMP,(83 x 12) Black,7 Slide in Ramps

Big Tex 10SR 9,990#,TA,SR DUMP,(83 x 12) Black,7 Slide in Ramps

VIN: 051956

Call for Quote

(606) 845-2702

Flemingsburg, KY

The 10SR from Big Tex Trailers is a medium-duty dump trailer equipped with a straight ram hydraulic lifting system. This unit comes standard with a lockable pump box, combo three-way rear gate and LED lights, and is powdercoated for a long-last build. Have confidence when hauling dirt, gravel, mulch, manure and any other light loads around the home or ranch.

  • Overview
  • Features/Specifications
  • Standard/Optional Equipment
  • Financing

Overview

Big Tex 10SR 9,990#,TA,SR DUMP,(83 x 12) Black,7 Slide in Ramps

The 10SR from Big Tex Trailers is a medium-duty dump trailer equipped with a straight ram hydraulic lifting system. This unit comes standard with a lockable pump box, combo three-way rear gate and LED lights, and is powdercoated for a long-last build. Have confidence when hauling dirt, gravel, mulch, manure and any other light loads around the home or ranch.

Max Payload:
6580 lbs.
Weight:
3410
Category:
Dump Trailers
Year:
2020
Condition:
New
Color:
Black
GVWR:
9990
Capacity:
6580

Features/Specifications

Features

Axle Two 5,200# Quick Lubricating w/Elec. Brakes
Jack 8,000# Top Wind Drop Leg
Tire ST235/80 R-16 Load Range E
Floor 10 Gauge Smooth Steel
Frame 6" x 2" Rectangular Tubing
Wheel 16" x 6"; Black Mod 6 Bolt
Finish Superior Quality Finish is Applied for a Highly Decorative and Protective Finish.
Lights L.E.D. D.O.T. Stop, Tail, Turn & Clearance
Tongue 6" Channel
Coupler 2-5/16" Adjustable Forged
Fenders 9" x 72" 14 Ga. Diamond Plate Double Square Broke
G.V.W.R. 9,990#
Elec. Plug 7-Way RV
Hitch Type Bumper Pull
Suspension Multi-Leaf Spring w/Equalizer
Finish (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish.
Safety Chains 1/4" Grd. 70 w/Safety Latch Hook (2 each)
Dump Body Sides 24" Tall Sides (12 Gauge)
Bed Crossmembers 3" Channel, 16" Centers
Dump Body Top Rail 2" x 2" Square Tubing
G.A.W.R. (Ea. Axle) 5,200#

Specifications

Pro Series Tandem Axle Single Ram Dump Trailer

Big Tex 10SR Pro Series Tandem Axle Single Ram Dump Trailer

Model Description
10SR-12XL 83" x 12' Pro Series Tandem Axle Single Ram Dump

Trailer Weights & Capacities

Length Empty Weight Payload Box Capacity
12' 3,160# 6,830# 6.1 Cubic Yards

Standard/Optional Equipment

Standard Equipment

  • Adjustable 2-5/16" Forged Coupler
  • 8,000# Top Wind Drop Leg
  • Lockable Pump & Battery Box Mounted in Front of Bed
  • 24" Tall, 12 Gauge Sides w/Formed Channel Supports
  • 10 Gauge Steel Floor
  • Tarp Mounting Brckets on Front of Bed
  • J-Hooks on Sides & Rear for Tarp Control
  • Stakepockets Along Sides
  • Self Contained Electric/Hydraulic Single Cylinder Lift
  • Power Up/Power Down Hydraulic Pump
  • 12V Interstate Deep Cycle Battery
  • 110V On-Board Battery Charger (5 Amp)
  • Premium Brand Axles
  • Cambered Axles w/Quick Lubricating Hubs
  • Forward Self Adjusting Electric Brakes on All Hubs
  • Grommet Mount Sealed Lighting
  • L.E.D. Lighting Package
  • Sealed, Modular Wiring Harness
  • Complete Break-A-Way System
  • Diamond Plate Fenders
  • 2" Square Tubing Top Rail on Dump Bed
  • Combo Gate (Barn Doors & Spreader Gate)
  • (4) 1/2" D-Rings Inside Bed to Secure Equipment
  • Spare Tire Mount
  • Radial Tires

Optional Equipment

Category Description
CARGO CONTROL Crank Style Roll Tarp
RAMPS 6.5 Slide In Ramp Package
TIRE/WHEEL Spare Tire (ST235/80 R-16 LR-E)
